MEAN WELL XDR-75-12 | 75W 12V 6.24A Ultra Slim Industrial DIN Rail Power Supply
PRODUCT DESCRIPTION
The MEAN WELL XDR-75-12 is a high-performance 75W ultra-slim industrial AC/DC DIN rail power supply designed to deliver a regulated 12V DC output at 6.24A. Featuring a compact 30mm-wide housing, an ultra-wide 85–305V AC input range, and 89% typical efficiency, it provides reliable power for industrial automation, control systems, and electromechanical equipment.
Advanced features include 200% peak power capability, remote ON/OFF control, DC OK relay monitoring, conformal-coated circuitry, and comprehensive electrical protections. Its fanless design, wide operating temperature range, and 5-year manufacturer warranty make it an excellent solution for demanding industrial applications.
KEY FEATURES
-
75W high-performance industrial AC/DC power supply
-
12V DC regulated output at 6.24A
-
Ultra-wide 85–305V AC input range
-
Supports 80–431V DC input
-
Ultra-slim 30mm housing for space-saving installation
-
High efficiency of 89% (typical)
-
200% peak power capability (150W for up to 5 seconds, subject to operating conditions)
-
500% transient peak current capability for 4ms
-
Adjustable output voltage from 12V to 15V DC
-
Built-in constant current limiting circuit
-
Short circuit, overload, overvoltage, and overtemperature protection
-
Integrated remote ON/OFF control
-
Built-in DC OK relay contact for power monitoring
-
Fanless design with natural air convection cooling
-
Wide operating temperature range from -40°C to +85°C (with derating above +60°C)
-
Conformal-coated PCB for basic moisture and dust protection
-
Ultra-low inrush current
-
Overvoltage Category III support under applicable standards
-
Suitable for installation on TS-35 DIN rails
-
Industrial safety certifications including IEC/EN 62368-1, IEC/EN 61558, and IEC/EN/UL 61010
-
Marine DNV approval and SEMI F47 compliance
-
5-year manufacturer warranty
TECHNICAL SPECIFICATIONS
-
Manufacturer: MEAN WELL
-
Model: XDR-75-12
-
Series: XDR-75
-
Power Supply Type: Industrial AC/DC DIN Rail
-
Rated Output Power: 74.88W
-
Output Voltage: 12V DC
-
Rated Output Current: 6.24A
-
Peak Output Power: 150W
-
Peak Output Current: 12.5A (5 seconds)
-
Input Voltage Range: 85–305V AC
-
DC Input Range: 80–431V DC
-
Input Frequency: 47–63Hz
-
Typical Efficiency: 89%
-
Adjustable Output Voltage: 12–15V DC
-
Ripple & Noise: 100mVp-p maximum
-
Voltage Tolerance: ±1.0%
-
Line Regulation: ±0.5%
-
Load Regulation: ±1.0%
-
Cooling Method: Natural Air Convection
-
Operating Temperature: -40°C to +85°C (with derating)
-
Operating Humidity: 20–95% RH, non-condensing
-
Dimensions: 30 × 125.2 × 116mm (W × H × D)
-
Weight: 496g
-
Mounting Type: DIN Rail TS-35
-
Protection Functions: SCP / OLP / OVP / OTP
-
Remote ON/OFF Control: Yes
-
DC OK Relay Contact: Yes
-
Conformal Coating: Yes
-
Manufacturer Warranty: 5 Years
-
Standard Packing: 24 Pieces per Carton
APPLICATIONS
-
Industrial automation systems
-
PLC control systems
-
Factory automation equipment
-
Industrial electrical control panels
-
Semiconductor manufacturing equipment
-
Electromechanical machinery
-
Industrial monitoring equipment
-
Process control systems
-
Industrial sensors and communication equipment
-
12V DC industrial equipment
SKU: 784-575
